143
1 - Windscreen defrosting/demist-
ing vents
2 - Front side windows defrost-
ing/demisting vents
3 - Central directional and
adjustable vents
4 - Side directional and adjustable
vents
5 - Air vents on driver side
6 - Air vents on passenger side
7 - Directional and adjustable
vents on front doors
8 - Front footwell air vents
9 - Rear footwell air vents
10 - Rear central directional and
adjustable vents
11 - Rear side directional and
adjustable vents
The climate control system can be
operated in one of the following
ways:
– manually, by selecting the func-
tions by means of the control panel
buttons;
– automatically, by means of the
system electronic control unit.
The air is let into the passenger
compartment through a set of vents
on the dashboard, on the front door
panels, on the rear central tunnel, on
door posts and on the floor as shown
in (fig. 112).
