290
COURTESY MIRROR LIGHTS
To replace the courtesy mirror
bulbs:
1) Lift the mirror cover A (fig. 38).
2) Remove the mirror by levering
in B.
IMPORTANT Be very careful
when removing the mirror to avoid
damaging its frame and the mirror
itself.
3) Remove the bulbs C (fig. 39)
releasing them from the side con-
tacts and replace them.
4) Refit the mirror inserting first
the upper edge and then pressing the
lower edge until it fits.
BOOT LIGHT
To replace the bulb:
1) Remove the lens by using a
screwdriver as a lever on clip A
(fig. 40).
2) Press the two sides of shield B
(fig. 41) at the fastening clips and
remove it.
fig. 38
L0A0136b
fig. 39
L0A0137b
fig. 40
L0A0139b
