291
3) Replace the clipped in bulb C .
4) Close the shield by clipping it
into its housing.
5) Refit the lens by inserting side D
first and then pressing the other side
to engage clip A.
DOOR LIGHTS (fig. 42)
To replace the bulb:
1) Remove the lens by using a
screwdriver as a lever on clip A.
2) Press the two sides of shield B at
the fastening clips and turn it.
3) Replace the clipped in bulb C.
4) Close the shield B by clipping it
into its housing.
5) Refit the lens by inserting side D
first and then pressing the other side
to engage clip A.
DOOR MIRROR LIGHTS
(fig. 43)
To replace the bulb:
1) Remove the lens by using a
screwdriver as a lever on clip A.
2) Remove the bulb holder B by
turning it anticlockwise.
3) Replace the clipped in bulb C.
4) Insert the bulb holder and turn
it clockwise.
5) Refit the lens by inserting side D
first and then pressing the other side
to fit it.
fig. 42
L0A0138b
fig. 43
L0A0141b
fig. 41
L0A0140b
