234
POWER SOCKET (fig. 203)
(where provided)
It is located on the right-hand side
of the boot.
Open cover A to use the socket.
The socket is powered when the
key is turned to MAR. It can be used
only for accessories with a maximum
intake of 15A (power 180W).
Do not use the socket for
power devices with a
higher intake than that
shown.
Prolonged current intake can
drain the battery and lead to
problems when starting the
engine.
SKI TUNNEL (where provided)
The tunnel can be used to trans-
port long objects (e.g. skis).
Introduce objects into the tunnel
from the boot.
Proceed as follows:
1) From the rear seat, lower the
armrest using handle A (fig. 204).
fig. 203
L0A0218b
fig. 204
L0A0076b
