232
The mobile net can be secured to
one of the two positions provided in
the front part of the boot (fig. 197-
198), by hooking it onto seats A and
B (fig. 199).
To secure the net, insert hooks A
(fig. 200) in seats B then push
downwards.
The net can be unhooked by slip-
ping it off upwards, by pressing
down button C on the attachment.
ANCHORING THE LOAD
The loads can be secured with belts
(not provided), attached to the spe-
cific rings (fig. 201-202) in the boot
corners.
fig. 197
L0A0046b
fig. 198
L0A0047b
fig. 199
L0A0099b
fig. 200
L0A0048b
fig. 201
L0A0219b
