289
A - Central ceiling light bulb.
B - Courtesy light bulbs.
3) Remove clipped in glass bulbs
from the bulb holders and replace
them.
4) Insert the bulb holders and turn
them clockwise.
5) Refit the ceiling light by insert-
ing first the rear part and then
pressing the front part until it fits.
IMPORTANT When refitting the
ceiling light check that the electrical
wires are positioned correctly.
GLOVE COMPARTMENT LIGHT
To replace the bulb:
1) Remove the lens by using a
screwdriver as a lever on clip A
(fig. 36).
2) Press the two sides of shield B
(fig. 37) at the fastening clips and
turn it.
3) Replace the clipped in bulb C.
4) Close the shield B by clipping it
into its housing.
5) Refit the lens by inserting side D
(fig. 36) first and then pressing the
other side to engage clip A.
fig. 37
L0A0135b
fig. 36
L0A0134b
fig. 35
L0A0133b
