Lantronix CoBox-Micro User Manual

CoBox-Micro Test Bed
2-7
Figure 2-6: Pinout Configurations
CON1 Serial Port
CON2 TTL Interface
5
1
9
6
GND
DTRA (out)
RxA (in)
TxA (out)
DCDA (in)
RTSA (out)
CTSA (in)
1 2
1112
+5VDC
TxA (out)RxA (in)
GND
CTSA (in)
DCDA (in)
RTSA (out)
DTRA (out)
TxB (out)
RxB (in)
TxB (out)
RxB (in)
GND
CON4 Serial Connector
1
3
