Lantronix Maestro E220 Series User Manual

Services
E220 Series Cellular Router User Guide 196
GPS
Services > Reporting Agent > GPS
LAN reporting agent provides real–time analysis by providing information of time, latitude, longitude,
altitude, device information. Further it allows to select the reporting agent and to enable sending the
data to server.
Sending Data
Services > Reporting Agent > Enable data Send
Captured data can be sent to any server using TCP/UDP/HTTP/HTTPS. When sending data over TCP,
a custom start of frame and end of frame sequence can be defined.
Back-up server can be configured – The router will start to send data to the back-up server if it fails to
send data to the main device management server 3 times. It will then continue to send data to the back-
up server until the back-up server fails or the device reboots.

Lantronix Maestro E220 Series Specifications

General

Brand	Lantronix
Model	Maestro E220 Series
Category	Network Router
Language	English
