2. Jumpers and Test Connection
FTDI Reset
(JP1)
FTDI OSC
Reset (JP2)
Raspberry Pi
Conn Power
(JP3 and JP4)
Serdes Test
125 MHz/200 MHz
Ref CLK Selection
(J13)
ADC Test
Selection (J21,
J22, and J24-J26)
FMC VADJ 1.8 V,
2.5 V, and 3.3 V
Selection (J6-J8)
VCCIO0 Power
Selection (J44)
VCCIO6 Power
Selection (J33)
Current
Measurement 2 Pin
Header (J3-J5, J32,
and J40)
Current Measurement
2 Pin Header
(J7-J9)
Current
Measurement 2 Pin
Header (J28-J30,
and J37)
Current
Measurement 2 Pin
Header (J34-J36,
J41-J43, J23, J31,
and J38)
Figure 2.1. Top View of CrossLink-NX Evaluation Board – Jumper Locations
