Appendix B. CrossLink-NX Evaluation Board Bill of Materials
Item
Reference
Qty
Part
PCB Footprint
Comments
Part Number
Manufacturer
Description
1
AG1,AF1,AE1,AD1,AC1,
AB1,AA1,AG2,AF2,AE2,
AD2,AC2,AB2,AA2,AG3,
AF3,AE3,AD3,AC3,AB3,
AA3,AG4,AF4,AE4,AD4,
AC4,AB4,AA4,AG5,AF5,
AE5,AD5,AC5,AB5,AA5,
AG6,AF6,AE6,AD6,AC6,
AB6,AA6,AG7,AF7,AE7,
AD7,AC7,AB7,AA7,AG8,
AF8,AE8,AD8,AC8,AB8,
AA8,AG9,AF9,AE9,AD9,
AC9,AB9,AA9,AG10,AF10,
AE10,AD10,AC10,AB10,
AA10,AG11,AF11,AE11,
AD11,AC11,AB11,AA11
77
T POINT R
TP
DNL
—
—
—
2
CN1
1
camconn_imx258_1x30
camconn
—
24-5804-030-000-829+
Kyocera / Sunny
Optical
Sony IMX214 CSI Camera
sensor
3
C1,C2,C3,C4,C7,C8,C9,
C11,C12,C13,C15,C18,
C19,C20,C24,C25,C27,
C29,C31,C33,C35,C37,
C38,C41,C42,C44,C46,
C47,C49,C50,C52,C53,
C54,C55,C57,C59,C60,
C65,C66,C67,C70,C71,
C72,C73,C75,C78,C83,
C84,C86,C92,C93,C95,
C96,C99,C100,C106,
C107,C113,C114,C115,
C116,C117,C118,C119,
C120,C124,C126,C127,
C128,C129,C130,C131,
C132
73
0.1uF 0201
C0201
—
GRM033R61E104KE14J
Murata
CAP CER 0.1UF 25V 10%
X5R 0201
4
C5,C14,C22,C39,C40,
C58,C64,C68,C69,C74,
C91,C94,C108,C121,
C122,C123,C125,C133,
C134,C138,C140
21
10uF-0603SMT
C0603
—
CL10A106MO8NQNC
Samsung
CAP CER 10UF 16V X5R
0603
