Lattice Semiconductor CrossLink-NX User Manual

CrossLink-NX Evaluation Board
User Guide
© 2019-2020 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
FPGA-EB-02028-1.3 47
Item
Reference
Qty
Part
PCB Footprint
Comments
Part Number
Manufacturer
Description
24
D1,D3,D4,D5,D6,D7,D8,
D9,D10,D11,D12,D13,
D14,D18,D19,D20,D21,
D22,D23,D24,D25,D26,
D27
23
LED_GREEN_0603
APT1608
—
150060GS75000
Wurth
LED GREEN CLEAR 0603
SMD
25
D2
1
ESDR0502N-UDFN6
UDFN6_040
—
ESDR0502NMUTBG
ON semi
TVS DIODE 5.5VWM
6UDFN
26
D15,D16
2
LED_YELLOW_0603
APT1608
—
150060YS75000
Wurth
LED YELLOW CLEAR 0603
SMD
27
D17
1
LED_RED_0603
APT1608
—
150060RS75000
Wurth
LED RED CLEAR 0603
SMD
28
D28
1
SCHOTTKY/VISHAY-
V12P10
V12P10
—
V12P10-M3/86A
Vishay
DIODE SCHOTTKY 100V
12A TO277A
29
D29,D30,D33,D34
4
1N4448W
1N4448W
—
1N4448WS
On Semi
DIODE GEN PURP 75V
150MA SOD323F
30
D31,D32,D35,D36
4
DFLS220L
DFLS220L
—
DFLS220L-7
Diodes
Incorporated
DIODE SCHOTTKY 20V 2A
POWERDI123
31
FB1,FB2,FB3,FB4,FB5,
FB6,FB7,FB8
8
MPZ1005S121CT000
FB0402
—
MPZ1005S121CT000
TDK Corporation
FERRITE BEAD 120 OHM
0402 1LN
32
F1
1
F1251CT-ND
154010
—
0154010.DR
Littelfuse Inc.
FUSE BRD MNT 10A
125VAC/VDC SMD
33
JP1,JP2,JP3,JP4,JP6,JP7,
JP8
7
JUMPER
Header_1x2
—
61300211121
Wurth
CONN HEADER VERT
2POS 2.54MM
34
JP5
1
Receptacle 20X2
HDR254-
2X20_socket
DNL
ESQ-120-23-T-D
Samtec Inc.
40 Position Elevated
Socket Connector
Through Hole
35
J1
1
Header 1x8
hdr_amp_872
20_8_1x8_10
0
DNL
22284081
Molex
CONN HEADER 8POS
.100 VERT TIN
36
J2
1
USB_MINI_B
USB_MINI_B-
1734035-2
—
1734035-2
TE Connectivity
AMP Connectors
CONN RCPT USB2.0 MINI
B SMD R/A
37
J3,J4,J5,J7,J8,J9,J23,J28,
J29,J30,J31,J32,J34,J35,
J36,J37,J38,J40,J41,J42,
J43
21
Header_2x1
Header_2x1
Regular
100 Mil
Header
—
—
—
38
J6,J26
2
Header_2x10
Header_2x10
—
61302021121
Wurth
CONN HEADER VERT
20POS 2.54MM
39
J10,J11,J12,J14,J15,J16
6
SMA
901-10309
DNL
901-10309
Amphenol
CONN SMA RCPT STR
50OHM EDGE MNT
