Item
Reference
Qty
Part
PCB Footprint
Comments
Part Number
Manufacturer
Description
94
R174,R175,R176,R177,
R178,R179,R180,R181,
R182,R183,R184,R185,
R186,R187
14
2K
R0402
—
ERJ-2GEJ202X
Panasonic
RES SMD 2K OHM 5%
1/10W 0402
95
SW1
1
SMD SW DIP-8
219-8MST
—
219-8MST
CTS
Electrocomponen
ts
SWITCH SLIDE DIP SPST
100MA 20V
96
SW2,SW3,SW4,SW5
4
Push Button
4psmd_switch
—
434153017835
Wurth
SWITCH TACTILE SPST-
NO 0.05A 12V
97
TP_VCCIO1,TP_VCCIO2,
TP_VCCIO3,TP_VCCIO4,
TP_VCCIO5,TP_VCCIO6,
TP_VCCIO7,
TP_VCC_CORE_V1P0,
TP_V1P0_VCCSD,
TP_V1P0_LDO,
TP_V1P2,
TP_V1P8_VCCPLLSD,
TP_V1P8_VCCAUXSD,
TP_V1P8_LDO,
TP_V1P8,TP_V2P8,
TP_V3P3,TP_V5P0,
TP_VCCIO0,TP_VADJ
20
TP_S_40_63
tp_s_40_63
DNL
—
—
—
98
TP1,TP2,TP3,TP4,TP5
5
TP_S_40_63
TP
DNL
—
—
—
99
TP6,TP7,TP8,TP9,TP10,
TP12,TP13
7
TestPoint
TP50
DNL
—
—
—
100
U1
1
FT2232HL
tqfp64_0p5_1
2p2x12p2_h1
p6
Customer
Supplied
FT2232HL
FTDI
IC USB HS DUAL
UART/FIFO 64-LQFP
101
U2
1
93LC56C-I/SN
so8_50_244
—
93LC56C-I/SN
Microchip
IC EEPROM 2KBIT 3MHZ
8SOIC
102
U3
1
LIFCL-40-BG400
LIFCL-40-
BG400
Customer
Supplied
—
—
—
103
U4
1
AK5DAF1-125.0000T2
XTAL_AK5DAF1
—
AK5DAF1-125.0000T2
Abracon LLC
XTAL OSC XO 125MHZ
3.3V LVDS
104
U5
1
AK5DAF1-200.0000T2
XTAL_AK5DAF1
DNL
AK5DAF1-200.0000T2
Abracon LLC
XTAL OSC XO 200MHZ
3.3V LVDS
105
U6
1
MX25L12833FM2I-10G
SO8_MX25L1
2833FM2I10G
—
MX25L12833FM2I-10G
Macronix
IC FLASH 128MBIT
133MHZ 8SOP
