09/2021 ECO Gold 117 / 134
19.6 USB interface
Important: First install the driver and then connect the thermostat to the PC.
19.6.1 Description
The ECO heating and cooling thermostats are equipped with a USB interface at the back of the control head. This en-
ables the connection of a PC and operation with the thermostat control software Wintherm Plus. In addition software
updates are possible via the USB interface.
The connecting lead is not included in the items supplied. When connecting up, make sure the correct plug is used.
LAUDA makes the drivers specially produced for the USB interface available free of charge for download at
http://www.lauda.de.
19.6.2 Installation of the USB driver
The driver is installed once per PC.
Supported operating systems: Windows ME, Windows XP, Windows 2000, Windows VISTA, Windows 7, Win-
dows 8 and Windows 10.
Execute the file "LAUDA_ECO_USB_Driver.exe". The window below opens.
1. Select the language and confirm with OK .
