1.2.2 VCI Connector
The VCI connector works as a vehicle communication interface device, which is
used to connect to the vehicle’s DLC (Data Link Connector) socket via the
diagnostic cable to read the vehicle data and then send it to the tablet.
Note: Remember to remove the VCI connector from the vehicle’s DLC after use.
1
Power indicator
Illuminates red while the VCI is powered up.
2
Vehicle indicator
Illuminates green and flashes when the VCI
is communicating with the vehicle.
