6 Diagnosis
6.1 Intelligent Diagnose
Through simple wireless communication between the tablet and VCI, you can easily get the VIN (Vehicle
Identification Number) information of the currently identified vehicle. Once the VIN is successfully
identified, the system will retrieve it from the remote server and then guide you to vehicle information
page without performing the step-by-step manual menu selection.
The vehicle information page lists all historical diagnostic records of the vehicle, which lets the technician
have a total command of the vehicle faults. In addition, a quick dial to Local Diagnose and diagnostic
function are also available on this page for reducing the roundabout time and increasing productivity.
*Notes: A stable network connection is required for this function. Before using this function, please make sure the
VCI is properly connected to the vehicle’s DLC port. For detailed connection, see Chapter 4.2.
Follow the steps below to proceed.
1. Tap
Intelligent Diagnose
to start pairing with the VCI.
2. After pairing is complete, the tablet starts reading the vehicle VIN.
A. If the VIN can be found from the remote server database, the following screen will appear:
• Tap
Diagnostic
to start a new diagnostic session.
• Tap
Scan History
to view its historical repair record. If there are records available, it will be listed on
the screen in sequence of date. If no records exist, the screen will show No Record.
• To perform other functions, tap
Quick access
to directly go to the diagnostic function selection screen.
Choose the desired one to start a new diagnostic session.
B. If the tablet failed to access the VIN information, the following screen will appear:
