LAUNCH X-431 PAD User's Manual
2.2 X-431 PAD Accessory Checklist
Common accessories for each X-431 PAD are same, but for different destinations,
the accessories of X-431 PAD (such as diagnostic software, testing connectors)
may vary. Please consult from the local agency or check the package list supplied
with X-431 PAD together.
Table 2-3: X-431 PAD common accessories and descriptions
No. Name Qt. Descriptions Picture
1
X-431 PAD
main unit
1
To connect X-431 PAD main
unit to DBScar diagnostic
connector
2
DBScar
diagnostic
connector
1
To connect to vehicle’s
DLC.
3
DBScar USB
cable
1
To connect X-431 PAD and
DBScar connector
4
Cigarette light
cable
1
To obtain power supply
from vehicle’s cigarette
lighter
5
Power
adaptor
1
To convert 100~240V AC
power supply to 12V DC
power supply.
6 Stylus 1
For clicking or writing on
the screen
7
SD card
(optional)
1 For extending memory
8
OBD II
extension
cable
1
9
Non-16PIN
connector
1 (optional)
