LeCroy WaveSurfer 400 Series User Manual

Front Panel Controls or Touch Screen Does not Operate (continued)
B
YES
O PEN DEVICE MANAGER
FROM
WITHIN WINDOWS
O PEN H UMAN
I NTERFACE DEVICES
UNPLUG ANY EXTERNAL
( FRONT OR REAR ) USB
DEVICES
A RE THEY
CORRECT
?
V ERIFY H UMAN
I NTERFACE DEVICES ARE
AS
SHOWN
NO
R EPLACE ENCODER
BOARD
V ERIFY USB CABLE IS
CONNECTED
BETWEEN
P ROCESSOR BOARD AND
ENCODER
BOARD
I S IT CORRECT ?
R EPLACE ENCODER
BOARD
R EPLACE P ROCESSOR
BOARD
YES
NO
C ORRECT CABLE
Maintenance 6-57
