6.10.7 Boot Up Sequence
PRESS THE FRONT
PANEL
POWER SWITCH
BOOT
UP PAST THE
WINDOWS 2000
SCREEN?
YES
BOOT
UP
PAST THE
WINDOWS 2000
SCREEN?
DOES THE
WINDOWS
DESKTOP
APPEAR
?
DOES THE
XSTREAMDSO
APPLICATION
LAUNCH
?
YES
NO
RESTORE IMAGE ON
HARD DRIVE
REPLACE
MOTHERBOARD
YES
NO
NO
YES
DOES
XSTREAM LOADING SCREEN
INDICATE
WAVEMASTER OR
WAVESURFER
WAVESURFER
PC MOTHERBOARD IS NOT
SUSPECTED
, VERIFY OTHER
APPLICATIONS
ARE NOT CAUSING
THE
PROBLEM.
UNPLUG PCI CARD
FROM
MOTHERBOARD
REPLACE PCI CARD
RESTORE IMAGE ON
HARD DRIVE
REPLACE FE/ACQ
CARD
NO
DOES
"NOT AUTHORIZED TO
RUN
ON THIS SYSTEM
APPEAR
"
NO NO
REINSTALL
XSTREAMDSO
SOFTWARE
YES
REPLACE PCI CARD
WAVEMASTER
