CS20, Description of the System
17
2.3.2 Power Concept
General Use the batteries, chargers and accessories recommended by Leica Geosystems to
ensure the correct functionality of the instrument.
Power options
2.3.3 Data Storage Concept
Description Data is stored on a memory device. The memory device can be an SD card, USB stick
or internal memory.
Memory device
While other SD cards can be used, Leica Geosystems recommends to only use
Leica SD cards and is not responsible for data loss or any other error that can
occur while using a non-Leica card.
Removing the SD card or USB stick while the field controller is turned on can cause loss
of data. Only remove the SD card or USB stick or unplug connecting cables when the
field controller is switched off.
Transfer Data Data can be transferred in various ways. Refer to "4.1.7 Connecting to a Personal
Computer".
SD cards can directly be used in an OMNI drive as supplied by Leica Geosystems. Other
PC card drives can require an adaptor.
Model Power supply
all CS models Internally by GEB331 battery, OR
Externally by GEV276 cable, OR
Externally by GEV219 cable, OR
If an external power supply is connected and the internal battery
is inserted, then the external power is used. The internal battery
is charged.
Please note: Charging functionality is not available for CS20 field
controller (823 164).
CTR20 Externally by the field controller.
Please note: Expansion pack support is not available for CS20 field
controller (823 164).
SD card: All field controllers have an SD card slot fitted as standard.
An SD card can be inserted and removed. Available
capacity: 1GB, 8GB.
USB stick: All field controllers have a USB port fitted as standard.
Internal memory: All field controllers have an internal memory fitted as
standard. Available capacity: 2 GB.
