CS20, Technical Data
39
Antenna
6.3.2 CTR20
Conformity to
national regulations
Frequency band
Output power < 100 mW (e. i. r. p.)
Antenna
Type Antenna Gain [dBi] Connector Frequency
band [MHz]
CS20, Bluetooth Integrated
antenna
2 - 2400-2480
CS20, RCS Integrated
antenna
1 - 2400-2480
CS20,
GSM (2G)/UMTS (3G)
Integrated
antenna
-- -
CS20, WLAN Integrated
antenna
1 - 2400-2480
• FCC Part 15 (applicable in US)
• Hereby, Leica Geosystems AG, declares that the product CTR20 is in compliance
with the essential requirements and other relevant provisions of Directive
1999/5/EC and other applicable European Directives. The declaration of conformity
can be consulted at
http://www.leica-geosystems.com/ce.
Class 1 equipment according European Directive 1999/5/EC (R&TTE)
can be placed on the market and be put into service without restric-
tions in any EEA member state.
• The conformity for countries with other national regulations not covered by the FCC
part 15 or European directive 1999/5/EC has to be approved prior to use and oper-
ation.
• Japanese Radio Law and Japanese Telecommunications Business Law Compliance.
– This device is granted pursuant to the Japanese Radio Law and the Japanese
Telecommunications Business Law.
– This device should not be modified (otherwise the granted designation number
will become invalid).
CTR20: 2402 - 2480 MHz
Type: /2 antenna
Gain: 2 dBi maximal
Connector: SMB (internal)
