CS20, User Interface
20
Key combinations
Home Switches to the Windows EC7 Start Menu.
Cameras Access the cameras.
Arrow keys Move the focus on the screen.
OK Selects the highlighted line and leads to the next logical
menu/ dialog.
Starts the edit mode for editable fields.
Opens a selectable list.
Key Function
Key Function
+
Hold Fn while pressing .
Switch to Windows.
+
Hold Fn while pressing .
Take a screenshot of the current screen.
+Hold Fn while pressing .
Increase the screen brightness.
+Hold Fn while pressing .
Decrease the screen brightness.
+Hold Fn while pressing .
Increase the volume for acoustic warning signals, beeps
and keypresses on the field controller.
+Hold Fn while pressing .
Decrease the volume for acoustic warning signals, beeps
and keypresses on the field controller.
+Hold Fn while pressing .
Lock/unlock the keyboard.
+Hold Fn while pressing .
Lock/unlock the touch screen.
+
Hold Fn while pressing .
Turn the torch on/off.
+Hold Fn while pressing or .
Switch to the previous/next page.

Leica CS20 Specifications

General

Type	Field Controller
Operating System	Microsoft Windows Embedded Handheld 6.5
Memory	1 GB RAM
Connectivity	Bluetooth
Camera	5 MP, autofocus
Interfaces	USB
GNSS	GPS/GLONASS
Expansion Slot	microSD card slot
Protection Rating	IP67
Operating Temperature	-30 °C to +60 °C
Processor	1.0 GHz dual-core ARM Cortex-A9
