CS10/CS15 & GS Sensors, Description of the System
20
2.3.2 Power Concept
General Use the batteries, chargers and accessories recommended by Leica Geosystems to
ensure the correct functionality of the instrument.
Power options
2.3.3 Data Storage Concept
Description Data is stored on a memory device. The memory device can be an SD card, USB stick
or internal memory.
Memory device
While other SD cards can be used, Leica Geosystems recommends to only use
Leica SD cards and is not responsible for data loss or any other error that can
occur while using a non-Leica card.
Removing the SD card or USB stick while the CS field controller is turned on can cause
loss of data. Only remove the SD card or USB stick or unplug connecting cables when
the CS field controller is switched off.
Transfer Data Data can be transferred in various ways. Refer to "4.1.13 Connecting to a Personal
Computer".
SD cards can directly be used in an OMNI drive as supplied by Leica Geosystems. Other
PC card drives can require an adaptor.
Model Power supply
all CS models Internally by GEB211/GEB212 battery, OR
Externally by docking station, OR
Externally by GEV235 cable, OR
Externally by GEV219 cable (only CS models with LEMO CBC01
connector module), OR
Externally by GDC221 car adapter
If an external power supply is connected and the internal battery
is inserted, then the external power is used.
CTR16/CTR17 Externally by CS field controller
GS05/GS06 Externally by CS field controller
GS08plus/GS12 Internally by GEB211/GEB212 battery, OR
Externally by GEV219 cable
If an external power supply is connected and the internal battery
is inserted, then the external power is used.
SD card: All CS field controllers have an SD card slot fitted as standard. An SD
card can be inserted and removed. Available capacity: 8 GB.
USB stick: All CS field controllers have a USB port fitted as standard.
Internal memory: All CS field controllers have an internal memory fitted as standard.
Available capacity: 1 GB.
