CS10/CS15 & GS Sensors, Operation
51
4.6 LED Indicators on CTR16/CTR17
LED indicators Description
The CTR16/CTR17 has a Light Emitting Diode indicator. It indicates the basic radio
status.
Diagram
Description of the LEDs
a) TPS radio LED
IF the is THEN
TPS radio LED green radio is in data mode and ready for connecting.
orange the CTR16/CTR17 is in configuration mode
purple radio is connecting.
blue radio has connected.
flashing blue data is being transferred.
red the CTR16/CTR17 is not ready to be used.
