CS10/CS15 & GS Sensors, Description of the System
24
2.5 CS Components
2.5.1 CS10
Upside of CS10
Underside of CS10
a) Slot Cover
b) Screen
c) Keyboard
d) Port cover
e) Power socket
f) USB A Host port
g) Docking station contacts
h) LEMO port (USB and serial)
i) USB Mini port
j) DSUB9 port
CS_001
b
a
c
d
f
e
g
h
i
j
a) Hand strap bottom clips
b) Hand strap
c) Battery compartment
d) Hand strap top clips
e) Slots
f) Slot cover
g) Stylus
h) GS05 contacts
i) SIM card slot
j) SD card slot
a
b
d
e
f
g
c
h
i
j
0012572_001
SD
