6.4.3 Technical Data
Description and use The table gives a description and the intended use of the GS08plus/GS12.
Dimensions
Connector •8 pin LEMO-1
• 5 pin SmartStation clip-on-contacts (GS12 only)
Mounting 5/8" Whitworth
Weight
Power
Battery internal
Electrical data
Type Description Use
GS08plus L1, L2 GPS, GLONASS
SmartTrack antenna
With CS10 or CS15 field controller
GS12 L1, L2, L5 GPS, GLONASS, Galileo
SmartTrack antenna
With CS10 or CS15 field controller
Type Height Diameter
GS08plus 0.071 m 0.186 m
GS12 0.089 m 0.186 m
GS08plus 0.8 kg including internal battery
GS12 1.1 kg including internal battery
Power consumption: 2.0 W typically
External supply voltage: Nominal 12 V DC ( ), voltage range 10.5 V-28 V
Type: Li-Ion
Voltage: 7.4 V
Capacity: GEB211: 2.2 Ah
GEB212: 2.6 Ah
Typical operating time: 7 h
The given operating times are valid for
• one fully charged GEB212 battery.
• 25°C. Operating times will be shorter when working in
cold weather.
Type GS08plus GS12
Frequency
GPS L1 1575.42 MHz
GPS L2 1227.60 MHz
GPS L5 1176.45 MHz -
GLONASS L1 1602.5625-1611.5 MHz
GLONASS L2 1246.4375-1254.3 MHz
Galileo E1 1575.42 MHz -
Galileo E5a 1176.45 MHz -
Galileo E5b 1207.14 MHz -
Galileo Alt-BOC 1191.795 MHz -
Gain Typically 37 dBi Typically 27 dBi
Noise Figure Typically <3dBi Typically <2dBi
