CS10/CS15 & GS Sensors, Technical Data
59
6.3 CTR16/CTR17 Technical Data
Description and use The CTR16/CTR17 is a high performance wireless data transfer device operating in the
2.4 GHz frequency band. The CTR16/CTR17 can be used on CS15 controller only for
communication to a total station with RH16/RH17 or TCPS29/30 attached.
Dimensions
Connector 5 pin interface port
Weight 0.155 kg / 0.342 lbs
Power
Environmental
specifications
Temperature
Protection against water, dust and sand
Humidity
Type Length [m] Width [m] Thickness [m]
CTR16/CTR17 0.131 0.069 0.053
Type CTR16/CTR17
Power consumption 100 mA nominal (5 V), 200 mA max.
Power supply From instrument
Operating temperature [°C] Storage temperature [°C]
-30 to +60 -40 to +80
Protection
IP67 (IEC 60529)
Dust tight
Protected against water jets
Waterproof to 1 m temporary immersion
Protection
Up to 100 %
The effects of condensation are to be effectively counteracted by periodically drying
out the CTR16/CTR17.
