Equipment setup
step-by-step
Step Description
1. Set up the tripod.
2. Mount and level the tribrach on the tripod.
3. Ensure that the tribrach is over the marker.
4. Place and lock the carrier in the tribrach.
GS10/GS25 GS08plus/GS12/GS14
with external RTK device
GS14/GS15
5. Screw the GNSS antenna
onto the carrier.
Screw the
GS08plus/GS12/GS14
onto the carrier.
Insert the data storage
device and the batteries
into the GS14/GS15.
6. Check that the tribrach is still level. Press the ON/OFF
button on the instru-
ment for at least 2 s to
switch on the instru-
ment.
7. Insert the SD card and
the batteries into the
instrument.
Hang the external
battery onto a tripod
leg.
Screw the GS14/GS15
onto the carrier.
8. Connect the instrument
to the GNSS antenna
using the antenna cable
and port ANT on the
instrument.
Hang the tripod bracket
onto a tripod leg and
attach the radio housing
onto the tripod bracket.
Check that the tribrach
is still level.
9. Connect the CS field
controller to the instru-
ment if necessary.
Connect the GEV205
cable to the
GS08plus/GS12 or the
GEV264 cable to the
GS14, to the external
battery and to the radio
housing.
Insert the SD card and
the battery into the CS
field controller.
10. To hang the instrument
on the tripod leg, use
the hook on the rear of
the unit. Or place the
instrument in the
container.
Insert the SD card and
the battery into the CS
field controller.
Connect the CS field
controller to the instru-
ment if necessary.
11. Insert the height hook
into the carrier.
Connect the CS field
controller to the instru-
ment if necessary.
To hang the CS field
controller on the tripod
leg, use the hook on the
hand strap.
12. Measure the antenna
height using the height
hook.
To hang the CS field
controller on the tripod
leg, use the hook on the
hand strap.
Insert the height hook
into the carrier.
13. Clip the antenna arm to
the GNSS antenna.
Insert the height hook
into the carrier.
Measure the antenna
height using the height
hook.
14. Screw the radio antenna
onto the antenna arm.
Measure the antenna
height using the height
hook.
Press the ON/OFF
button on the instru-
ment for at least 2 s to
switch on the instru-
ment.
