CS10/CS15 & GS Sensors, Technical Data
56
Environmental
specifications
Temperature
Protection against water, dust and sand
Humidity
Interfaces
Data format for
RS232
The default values are:
Ports
Type Operating temperature [°C] Storage temperature [°C]
CS10/CS15 -30 to +60 -40 to +80
Internal
battery
-20 to +55 -40 to +70
Type Protection
CS10/CS15 IP67 (IEC60529)
Dust tight
Waterproof to 1 m temporary immersion
Type Protection
CS10/CS15 Up to 100 %
The effects of condensation are to be effectively counteracted by peri-
odically drying out CS10/CS15.
Type RS232 USB Host USB OTG Bluetooth WLAN*
CS10/CS15 LEMO port or
DSUB9
LEMO port or
USB A
LEMO port,
USB Mini-AB
or docking
station
contacts
Class 2 802.11b/g
* WLAN is only available for certain models.
Baud rate: 115200
Parity: None
Terminator: CR/LF
Data bits: 8
Stop bits: 1
Type 8 pin LEMO-1 DSUB9 USB A
Host
USB Mini Docking station
contacts
CS10/CS15 For power and/or
communication
For communication For power and/or
communication
