Voltage
V~
Frequency
Hz
Capacity
W
Temperature
°C
Air flow
l/min.
Drive speed m/min.
Noise emission level L
pA
(dB)
Dimensions
Uniplan S mm
Dimensions
Unifloor S mm
Weight
Uniplan S kg
Weight
Unifloor S kg
TECHNICAL DATA
230 # 120 # 100 #
50 / 60 50 / 60 50 / 60
2300 1800 1500
20 – 620 20 – 620 20 – 620
Max. 300 Max. 250 Max. 250
1.0 – 7.5 1.0 – 7.5 1.0 – 7.5
67 65 65
420×270 ×210 420×270 ×210 420×270 ×210
420×270 ×215 420×270 ×215 420×270 ×215
11.5 11.5 11.5
14.0 14.0 14.0
# Mains voltage cannot be switched over
CCA certified
Protection Class Ι
Danger! Unplug the tool before opening it, as live compo-
nents and connections are exposed.
Incorrect use of hot air tools can present a fire and explosion
hazard, particularly in the proximity of flammable materials
and explosive gases.
The tool must be operated under supervision.
– Heat can ignite flammable materials which are not in view.
– Interference can impair the welding process when taking
place in the vicinity of high-frequency installations.
For personal protection, we strongly recommend the tool to
be connected to an RCCB (Residual Current Circuit Breaker)
before using it on construction sites.
The rated voltage stated on the tool must correspond with
the mains voltage.
Danger of getting burned! Do not touch the heater tube and
nozzle when they are hot. Let the tool cool down. Do not
point the hot air flow in the direction of people or animals.
Protect the tool from damp and wet.
FI
230
120
WARNING
CAUTION
Only connect the tool to a receptacle outlet with protective
earth conductor. Any disconnection of the protective earth
conductor, in or outside the tool is dangerous!
Only use extension lead with a protective earth conductor.
Approval Marks
2
3
1
