TOOL DESCRIPTION LEISTER Unifloor S
6
2
3
4
12
11
7
20
18
5
Main components
1. Housing
2. Mains cable
3. Hot air blower
4. Welding nozzle with cover
5. Connection hose
6. Welding rod pressure roller
7. Drive roller
8. Chassis
9. Wall switch-off
10. Support bracket
11. Manual air valve
12. Air filter
14
13
Operating components
13. Drive switch
14. Potentiometer for welding speed
15. Air blower switch
16. Potentiometer for air temperature
17. Two stage switch for airflow
18. Swivel lever
Steering equipment
19. Welding rod guide tube
20. Guide roller
21. Fuse T 1.0 A 230 V~
T 1.2 A 120 V~
19
8
10
9
6
1
1
2
0
3
15 16 17
Detail A
Cover open
4
Cover closed
21
