10
2.2.3 Environmental
FOR INDOOR USE ONLY
Reference conditions. All accuracies stated at
23°C ± 1°C
Operating temperature 0°C to 50°C (32°F to 122°F)
Temperature coeff. of current ≤ ±0.15% of rdg per °C
Temperature coeff. of voltage ≤ ±0.15% of rdg per °C
Maximum relative humidity 80% for temperatures up to
31°C (87°F) decreasing linearly to 50% relative humidity
at 40°C (104°F)
Maximum operating altitude 2000m
2.2.4 Mechanical
Dimensions ....................... Length 300mm (12 inches)
Width 98mm (3.75 inches)
Depth 52mm (2 inches)
Weight inc. batteries.......... 820g / 1.8lbs.
Case material .................... Bayblend T85
Jaw opening ...................... 60mm
Jaw capacity...................... 58mm diameter
Accessories....................... Voltage probes
Crocodile Clips
Carrying case
Operator’s manual
Cleaning ............................ The unit can be cleaned
with an Isopropanol
impregnated cloth.
Do not use abrasives or
other solvents.
2.2.5 Power-up
At power-up the following screen is displayed for 5
seconds indicating the battery status. The remaining
battery lifetime is displayed, with and without the backlight.
When the display changes to the digital mode, the
instrument is ready for use.
