4
C. CROSSHAIR LED INDICATORS
The Crosshair LED Indicators are constantly showing the boat’s CURRENT ROLL AND PITCH POSITIONS
compared to the HOME ROLL AND PITCH POSITION. As the boat rocks back and forth on the water, the Auto
Glide is constantly tracking the boat’s position and displaying it on the crosshairs. Roll and Pitch Positions are
illuminated independently of each other on the Horizontal and Vertical Crosshairs.
The Auto Glide is constantly measuring the boat’s CURRENT ROLL AND PITCH POSITIONS
at the rate of 25
times per second. However, that information is dampened so that the Auto Glide does not overreact to every
small movement of the boat. You will most likely notice the dampening because the CURRENT ROLL AND
PITCH POSITIONS are displayed on the Key Pad slower than the boat is actually moving.
The following examples illustrate how the boat’s CURRENT ROLL AND PITCH POSITIONS are shown to you on
the Key Pad’s Crosshair LED Indicators:
EXAMPLE #1: THE BOAT CURRENT ROLL AND PITCH POSITIONS MATCH THE AUTO GLIDE’S
HOME ROLL AND PITCH DEFAULT POSITIONS:
