Page 51
CBX40UHV
5. Indoor Blower Test
Blower Test Mode
AHC in Idle Mode
(No heating cooling or indoor fan
operation)
To enter Indoor Blower Test Mode,
push and hold button next single
character LED display until — (Solid
bar), then release button.
Turn room thermostat to OFF
(Solid bar) starts
blinking on single
character LED display.
Push and hold button until the solid A
symbol is displayed on the single
character LED display, then release
button.
Control will cycle the indoor blower motor for ten seconds at 70% of maximum air for selected capacity size unit. Control will automatically
exit Blower Test Mode.
Yes
No
Figure 41. Indoor Blower Test
