Step Screw (quantity) Color
Torque
1
M2 × 3 mm, flat-head, nylon-coated (6)
Black 0.181 Nm
(1.85 kgf-cm)
When you install the hinge kit:
Ensure that all the connectors are attached firmly.
2050 Integrated camera and microphone combo card
For access, remove these FRUs in order:
• “1140 LCD unit” on page 85
• “2010 LCD bezel assembly” on page 91
• “2020 LCD panel” on page 92
Chapter 8. Removing or replacing a FRU 99
