ThinkPad E14/R14/S3 Gen 2
Removal steps of the LCD bezel assembly
ThinkPad E15
Removal steps of the LCD bezel assembly
When installing:
Ensure that all the latches are attached firmly.
2020 LCD panel
ThinkPad E14/R14/S3 Gen 2
Removal steps of the LCD panel
For access, remove this FRU in order:
• “1140 LCD unit” on page 85
• “2010 LCD bezel assembly” on page 91
92
E14/R14/E15/S3 Gen 2 Hardware Maintenance Manual
