Table 10. Major FRUs (continued)
No. FRU descriptions
Self-service
CRU
Optional service
CRU
3
Camera/mic combo board
No No
4
Microphone rubber No No
5
WLAN antenna kits No No
6
LED and camera cable assembly No No
7
LCD cover assembly No No
8
LCD elastic tapes No No
9
Hinge kits No No
Note: Depending on the computer model, your computer might look different from the illustration above.
Miscellaneous parts
Table 11. Miscellaneous part
FRU descriptions
Self-service
CRU
Optional-service
CRU
Screw kit
• For ThinkPad E14/R14/S3 Gen 2:
– M2 x L2, black (4)
– M2 x L2.5, silver (8)
– M2 x L2.5, black (2)
– M2 x L4, silver (6)
– M2 x L2, black (3)
– M2.5 x L2.2, black (6)
– M2.5 x L5, black (4)
– Spec
• For ThinkPad E15:
– M2 x L1.8, silver (4)
– M2 x L2.5, silver (6)
– M2 x L4, black (5)
– M2 x L3, black (6)
– M2.5 x L5, black (4)
– Spec
No No
Label kit:
• GEO label
• Spec
No No
Connector and cable guide
This topic provides information to help Lenovo authorized service technicians identify connectors and cables
for replacement purpose. To view each FRU and the exploded illustration of the computer, see “Major FRUs”
on page 50 and “LCD FRUs” on page 54.
56
E14/R14/E15/S3 Gen 2 Hardware Maintenance Manual
