When you install the system board:
Ensure that all the connectors are attached firmly to the system board.
1160 Keyboard assembly
For access, remove these FRUs in order:
• “1010 Base cover assembly” on page 65
• “1020 Hard disk drive and cable” on page 66
• “1030 Memory module” on page 67
• “1040 M.2 solid-state drive and brackets” on page 68
• “1050 Speaker assembly” on page 73
• “1060 Built-in battery” on page 73
• “1070 Wireless LAN card” on page 74
• “1080 Thermal fan assembly” on page 75
• “1090 I/O card and cable” on page 78
• “1110 Power button/fingerprint reader module and cable” on page 82
• “1120 Coin-cell battery” on page 83
• “1130 Trackpad cable and trackpad” on page 84
• “1140 LCD unit” on page 85
• “1150 System board” on page 87
2010 LCD bezel assembly
For access, remove this FRU:
• “1140 LCD unit” on page 85
Chapter 8. Removing or replacing a FRU 91
