Removal steps of M.2 2280 solid-state drive and brackets
Step Screw (quantity) Color Torque
1
M2 × 4 mm, flat-head, nylon-coated (2)
Black 0.181 Nm
(1.85 kgf-cm)
Step Screw (quantity) Color Torque
3
M2 × 4 mm, flat-head, nylon-coated (1) Black 0.181 Nm
(1.85 kgf-cm)
Chapter 8. Removing or replacing a FRU 71
