Table6.HarddiskdriveLEDsfortheadd-onSASRAIDadapterconguration(somemodels)
Description
GreenLED1
(bottom)AmberLED2(top)
Harddiskdriveisnotpresent.
OffOff
Harddiskdriveispresentbutisnotactive.
OnOff
Harddiskdriveispresentandactive.Blinking
Off
Serverisintheprocessoflocatingtheharddiskdrive.
BlinkingBlinking
RAIDhasfailed.
OffOn
Harddiskdriveisrebuilding.BlinkingBlinking
TheEthernet1andEthernet2connectorshavetwostatusLEDsthatindicatetheLANconnectionand
activityoftheconnection.
Table7.EthernetLEDs
LEDStateColorDescription
OnGreen10/100/1000Mblinked
Blinking
Green10/100/1000Mbactivity
RJ-45linkage/activity(left)
OffOff
NoLANconnection.
On
Amber1000Mblinkedandactive
OnGreen
100Mblinkedandactive
RJ-45speed(right)
OffOff
10MbmodeornoLANconnection.
14ThinkServerUserGuide
