5.Presstherisercardassembly(mighthavingaPCIcardinstalled)downintotheappropriatePCIcardslot
onthesystemboard.Then,closetheretentiontabtosecurethePCIcard(installedontherisercard
assembly)andtheninstallthefasteningscrewtosecuretherisercardassemblyinplace.
Note:TherisercardassemblymighthaveaPCIcardalreadyinstalledonit.CarefullytthePCIcard
intotheserver.
Figure21.Installingtherisercardassembly
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheinstallation,goto“Completingthepartsreplacement”onpage67
.
Removingtherisercardassembly
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstandingthe“Safetyinformation”
onpageiii
and“Guidelines”onpage19.
ThissectionprovidesinstructionsonhowtoremovetherisercardassemblywithaPCIcardinstalled.
Toremovetherisercardassembly,dothefollowing:
