Lenovo ThinkServer RD230 - Locating Server Components; Locating Parts on the System Board

Locatingservercomponents
Thefollowingillustrationshowsthelocationsofthemajorcomponentsinyourserver.
Figure4.Servercomponentlocations
1Lefthandleofthechassis
6Heatsinkassemblyandmicroprocessor(s)underneath
2Slimopticaldrive7Systemfans
3PCIcard
8Righthandleofthechassis
4Memorymodules
9Mountingpointsforthe3.5-inchharddiskdrives
5Powersupplyassembly
Locatingpartsonthesystemboard
Thefollowingillustrationsshowthelocationsofthepartsonthesystemboard.
Chapter4.Locatingparts,controls,LEDs,andconnectors15
