Locatingconnectorsonthebackplane

Thefollowingillustrationshowstheconnectorlocationsonthebackplane.

Figure7.Backplaneconnectorlocations

1Powerconnector2

3Opticaldrivepowerconnector

2Powerconnector1

4Mini-SASsignalcableconnector

18ThinkServerUserGuide
