3.Ifyouareinstructedtoreturntheremovedharddiskdrive,followallpackaginginstructionsanduseany
packagingmaterialsthataresuppliedtoyouforshipping.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheremovalprocedure,goto“Completingthepartsreplacement”onpage67.
Installingahot-swapharddiskdrive
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstandingthe“Safetyinformation”
onpageiiiand“Guidelines”onpage19.
Thissectionprovidesinstructionsonhowtoinstallahot-swapharddiskdrive.Thissectionappliesonlyto
servermodelsthatsupporthot-swapharddiskdrives.
Attention:Tomaintainpropersystemcooling,donotoperatetheserverformorethan10minuteswithout
eitheradriveorallerpanelinstalledineachdrivebay.
Notes:
1.Youdonothavetoturnofftheserverfortheinstallationofahot-swapharddiskdrive.
2.ThecablescomewiththeSATAharddiskdriveoptionkitwillnotbeusedinthisserver.
Toinstallahot-swapharddiskdrive,dothefollowing:
1.Rotatethedrivetrayhandle2oftheharddiskdrivetrayassembly1totheopenposition.Then,grasp
thehandleandpullthedrivetrayassemblyoutofthebay.
Figure18.Removingtheharddiskdrivetrayassembly
32ThinkServerUserGuide
