c.HoldthebatterycardassemblywiththebatterysideupandtheJ2board-to-boardconnectorlining
upwiththeJ7BBUconnector1ontheRAIDcontroller.Carefullypressthebatterycardassembly
ontotheRAIDcontrollersothatthetwoconnectorsarermlyjoined.Then,securethebattery
cardassemblytotheRAIDcontrollerwiththethreescrewsandthestandoffsthatcomewiththe
batterycardassemblyaccessorykit.
Figure30.Installingthebatterycardassembly
1J7BBUconnector
5.See“InstallingaPCIcard”onpage38andfollowthoseinstructionstoinstalltheRAIDcontroller.
6.ConnecttheminiSASsignalcabletotheRAIDcontrollerandminiSASsignalcableconnectoronthe
backplane.See“Locatingconnectorsonthebackplane”onpage18
Note:Usethe440mm(17.32inches)miniSASsignalcable.
Figure31.ConnectingtheminiSASsignalcable
1Ports0-3
2Ports4-7(reservedforuse)
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheinstallation,goto“Completingthepartsreplacement”onpage67
.
Chapter5.Installing,removing,orreplacinghardware47
