3.Removetheeightscrewsthatsecuretheheatsinkassembly1-8andgentlyliftouttheheatsink
assembly.
Figure43.Removingtheheatsinkassembly
1-8Screws
9Airow
10Indicatesthefrontofthechassis
4.Ifyouareinstructedtoreturntheheatsinkassembly,followallpackaginginstructionsanduseany
packagingmaterialsthataresuppliedtoyouforshipping.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Toinstalltheheatsinkassembly,see“Installingtheheatsinkassembly”onpage56.
Installingtheheatsinkassembly
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstandingthe“Safetyinformation”
onpageiiiand“Guidelines”onpage19.
Thissectionprovidesinstructionsonhowtoinstalltheheatsinkassembly.
56ThinkServerUserGuide
