2Coin-cellbattery
Yourserverhasaspecialtypeofmemorythatmaintainsthedate,time,andconfigurationinformationfor
built-infeatures.Thecoin-cellbatterykeepstheinformationactivewhenyouturnofftheserver.
3SATAconnector1(ports4–7)
Usedtoconnecttomini-SASports4-7onthebackplanefor2.5-inchdrives.
4SATAconnector0(ports0–3)
UsedtoconnecttotheMini-SASports0-3onthebackplane.
56Frontpanelconnector
Usedtoconnecttothefrontpanelboard.
7SDmoduleconnector
UsedtoconnectanSDmodule.
8Risercardassembly1slot
Usedtoinstalltherisercardassembly1.
9TSMPremiummoduleconnector
UsedtoconnectaTSMPremiummoduletoenableadvancedremotemanagementfunctionsonyourserver.
10TPMconnector
UsedtoconnectaTPM.TPMisasecuritychipthatisusedtoenhanceserversecurity.
11PCIeslot
UsedtoinstallasupportedPCIecard.ForinformationaboutsupportedPCIecards,see“Rearviewof
theserver”onpage21.
12Risercardassembly2slot
Usedtoinstalltherisercardassembly2.
13RAIDupgradekeyconnector
UsedtoconnectaThinkServerRAID110iupgradekey.
14Powersupplyconnector2
Usedtoconnectthepowersupply2.
15Powersupplyconnector1
Usedtoconnectthepowersupply1.
