Installingorremovingtheopticalmodule
Theopticalmoduleenablesyoutoconnecttwonetworkdeviceswithopticalfibercables.Theoptical
moduleisneededonlyonsomePCIecards.
Note:TheopticalmoduleisextremelysensitivetoESD.Ensurethatyoureadandunderstand“Handling
static-sensitivedevices”onpage54firstandcarefullyperformtheoperation.
Installingtheopticalmodule
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiii
and“Guidelines”onpage53.
Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
Notes:
•TheopticalmoduleandthePCIecardmightlookdifferentfromtheillustrationinthistopic.
•Beforeyouinstalltheopticalmodule,ensurethatthePCIecardthatrequirestheopticalmoduleis
installedintheserver.See“InstallingaPCIecard”onpage81
.
Toinstalltheopticalmodule,dothefollowing:
1.LocatethetwoholesattherearofthePCIecardforinstallingtheopticalmodule.
2.Touchthestatic-protectivepackagethatcontainstheopticalmoduletoanyunpaintedsurfaceonthe
outsideoftheserver.Then,taketheopticalmoduleoutofthepackage.
3.Withtheopticalmodulehandleintheopenposition,inserttheopticalmoduleintooneofthetwo
holesinthePCIecard.
Figure48.Installingtheopticalmodule
Chapter6.Replacinghardware85
