Lenovo ThinkServer RD350 - Server Components

EthernetstatusLED
ColorStatus
Description
Amber
On
Theconnectionspeedis1000Mbps.
GreenOn
Theconnectionspeedis100Mbps.
1Left
None
Off
Theconnectionspeedis10Mbps.
GreenOn
TheserverisconnectedtoaLAN.
None
Off
TheserverisdisconnectedfromaLAN.
2Right
Green
BlinkingTheLANisconnectedandactive.
9Serialconnector
Usedtoattachadevicethatusesa9-pinserialconnector.
11VGAconnector(DB-15)
UsedtoattachaVGA-compatiblevideodevice,suchasaVGAmonitor.
Servercomponents
Thistopicprovidesinformationtohelpyoulocatethecomponentsofyourserver.Formoreinformation
aboutmajorcomponents,seetherelatedtopicsin“Locations”onpage15.
Toremovetheservercoverandthecoolingshroudandgainaccesstotheinsideoftheserver,see
“Removingtheservercover”onpage55and“Removingandreinstallingthecoolingshroud”onpage58.
Thechassisconfigurationvariesbymodel.Thefollowingillustrationsshowthetwochassisconfigurations
basedonthesupporteddrives.
•Servermodelswith3.5-inchdrives
•Servermodelswith2.5-inchdrives
Note:Dependingonthemodel,yourservermightlookslightlydifferentfromtheillustrationsinthistopic.
Chapter3.Productoverview23
