Thefollowingillustrationshowsthecomponentsofservermodelswith3.5-inchdrives.
Figure7.Componentsofservermodelswith3.5-inchdrives
1Oneortwohot-swapredundantpowersupplies2DIMMs(varybymodel)
3Systemboard4Coolingshroud
5Backplanefor3.5-inchdrives
6ThinkServerRAIDSuperCapacitorModule(availableon
somemodels)
7Rackhandle(right)
83.5-inch-drivearea
9Rackhandle(left)10Slimopticaldrive(availableonsomemodels)
11Systemfans12Heatsink(s)withmicroprocessor(s)underneath
13Securedigital(SD)module(availableonsome
models)
14Risercardassembly1
15Risercardassembly2
24ThinkServerRD350UserGuideandHardwareMaintenanceManual
