Thefollowingillustrationshowsthecomponentsofservermodelswith2.5-inchdrives.
Figure8.Componentsofservermodelswith2.5-inchdrives
1Oneortwohot-swapredundantpowersupplies2DIMMs(installedmemorymodulesvarybymodel)
3Systemboard4Coolingshroud
5Backplanefor2.5-inchdrives
6ThinkServerRAIDSuperCapacitorModule(availableon
somemodels)
7Rackhandle(right)
82.5-inch-drivearea
9Rackhandle(left)10Slimopticaldrive(availableonsomemodels)
11Systemfans12Heatsink(s)withmicroprocessor(s)underneath
13SDmodule(availableonsomemodels)
14Risercardassembly1
15Risercardassembly2
CRUsarepartsthatcanbeupgradedorreplacedbythecustomer.IfaCRUisdeterminedtobedefective
duringthewarrantyperiod,areplacementCRUwillbeprovidedtothecustomer.Customersareresponsible
forinstallingtheself-serviceCRUsforthisproduct.Customersalsocaninstalloptional-serviceCRUs,which
mightrequiresometechnicalskillsortools,orrequestthatatechnicianinstalltheoptional-serviceCRU
underthetermsoftheapplicablewarrantyservicetypeforyourcountryorregion.
Non-CRUsmustbereplacedonlybytrainedservicetechnicians.
ThefollowingtableliststhemajorFRUsinyourserverandtheCRUidentificationinformation.Foracomplete
listingofFRUinformation,suchasFRUpartnumbersandsupportedservermodels,goto:
http://www.lenovo.com/serviceparts-lookup
Notes:
•BeforeservicingaLenovoproduct,ensurethatyoureadandunderstand“Safetyinformation”onpageiii
.
•UseonlypartsprovidedbyLenovo.
